Adapter E-2000™ PC, blue/blue, ceramic SM

1.Standardisation:IEC61754-15, DIN EN 186270

2.Excellent changeability and directivity



Inquiry

 Adapter E-2000™ PC, blue/blue, ceramic SM, C



Description

Adapter E-2000™ with semi-transparent dust caps. M2 nuts pre-mounted.
Color coding: adapter / frames.



Specification

Standardisation acc. to
  IEC61754-15, DIN EN 186270
Connector
  type (A)		  E-2000™
Number of
  connectors(A)		 1
Polishing
  connector (A)		  PC
Attenuation
  grade IL - connector (A)		 C
Protection
  class (IP) connector (A)		 20
Lever- frame-coding connector
  (A) 		 color
Connector color (A)  blue
Frame color
  connector (A)		  blue
Fiber type  Singlemode (SM)
Sleeve
  material		 ceramic
Adapter fastening method  end cap
Material
  plasticX		 end cap
Dimensions  74.7 / 42 x 22 x 9.35
  mm
Dispatch
  weight		 9
Unit of
  dispatch weight		 G





Adapter E-2000™ (LSH) PC, blue/blue, ceramic SM, Grade C
E-2000™ adapter (LSH) singlemode, simplex adapter in acc. with IEC 61754-15 and EN 186270. Adapter body plus flange and two integral hexagonal nuts M2 for screw mounting. Zirconia (ceramic) alignment sleeve, blue housing (singlemode), blue coding frame, material PBT / UL 94 V-0, integral self-closing metal laser protection flaps, semitransparent plastic dust cover, allowing optical testing with test lasers without removing the cover. The adapter is qualified in accordance with IEC 61753-1 for category U (uncontrolled environment).



Optical specifications:
  Delta insertion loss<or= 0.2 dB, testing method acc. to IEC 61300-3-4


Mechanical specifications:
Mating cycles: min. 1000
Pull-out force: min. 70 N



 Modules & Accessories

Frame E-2000™ Adapter, code 1, red
 Frame E-2000™ Adapter, code 2, brown
 Frame E-2000™ Adapter, code 3, yellow
Frame E-2000™ Adapter, code 4, orange
Frame E-2000™ Adapter, code 5, violet
 Frame E-2000™ Adapter, code 6, white
